| Video |
H.264 (Baseline/Main/High, H.265 (Main, AV1, Motion JPEG; up to 2688×1512 (16:9, 2016×1512 (4:3, 1280×800 (16:10; up to 25/30 fps with Forensic WDR in all resolutions; up to 100/120 fps without WDR in all resolutions; Axis Zipstream for H.264/H.265/AV1; up to 20 unique streams; multi-view streaming with up to 7 individually cropped out view areas; controllable frame rate and bandwidth; VBR/ABR/MBR; low latency mode |
| Image Settings |
Saturation, contrast, brightness, sharpness, white balance, day/night threshold, local contrast, tone mapping, exposure mode, exposure zones, defog, barrel distortion correction, compression, rotation 0°/90°/180°/270° including corridor format, mirroring, dynamic text and image overlays, overlay widget, privacy masks, lock aperture, target aperture |
| PTZ / Orientation |
Digital PTZ and optical zoom; pan ±180°, tilt −42° to +89°, rotation ±180°; preset positions; limited guard tour and tour recording (up to 10 tours, max 16 minutes each; control queue; on-screen directional indicator |
| Audio Encoding |
AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz, LPCM 48 kHz; configurable bitrate |
| Networking |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II, DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/RTSPS, RTCP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, secure syslog (UDP/TCP/TLS, link-local address (ZeroConf |
| System Integration |
Open API with VAPIX and AXIS Camera Application Platform (ACAP; metadata support; one-click cloud connection; ONVIF Profiles G, M, S, and T; SIP support for VoIP using peer-to-peer or PBX integration |
| Event Triggers |
Application events; audio detection and audio clip state; device status (temperature, casing open, fan failure, IP change, network lost, live stream active, shock detected, ring power overcurrent, system ready; digital audio status; edge storage (recording, disruption, health issues; I/O (digital input, virtual input, manual trigger; MQTT (stateless; scheduled and recurring events; video events (average bitrate degradation, day/night mode |
| Event Actions |
Play/stop audio clips; make/answer/end SIP calls; switch day/night mode; start/stop guard tours; toggle I/O (once or while rule is active; control IR illumination and status LEDs; publish MQTT messages; send HTTP/HTTPS/TCP/email notifications; overlay text; go to PTZ presets; record to SD card or network share with pre/post buffers; upload images/video (FTP/SFTP/HTTP/HTTPS/network share/email; send SNMP traps; erase configuration |
| Analytics |
Included: AXIS Object Analytics (humans, vehicles and vehicle types with scenarios such as line crossing, object in area, time in area, counting, occupancy, tailgating, PPE monitoring BETA, motion in area/line crossing, AXIS Scene Metadata, AXIS Image Health Analytics, AXIS Live Privacy Shield, AXIS Video Motion Detection, audio detection; supports AXIS Perimeter Defender and AXIS License Plate Verifier; supports third-party ACAP applications |
| Cybersecurity |
Axis Edge Vault hardware-based cybersecurity platform; secure keystore in secure element (CC EAL 6+, FIPS 140-3 Level 3; signed OS and secure boot; signed video; encrypted filesystem (AES-XTS-Plain64 256-bit; brute-force delay protection; HTTPS/HSTS, TLS 1.2/1.3; IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2; MACsec; host-based firewall; Axis Cryptographic Module; compliance with ETSI EN 303 645 and FIPS/NIST guidelines |
| Approvals |
Product markings: UL, CE, FCC, ICES, KC, VCCI, RCM; EMC: CISPR 32/35, EN 55032/55035, EN 50121-4, EN 61000-3-2/-3-3, EN 61000-6-1/-6-2, RCM AS/NZS CISPR 32 Class A, ICES Class A, VCCI Class A, FCC Part 15 Class A, KS C 9832/9835; safety: IEC/EN/UL 62368-1, IEC/EN 62471 risk group exempt; environment: IEC/EN 60529 IP66/IP69, IEC/EN 62262 IK10, ISO 20653 IP6K9K, ISO 21207, NEMA 250 Type 4X |
| Storage Conditions |
−40 °C to 65 °C (−40 °F to 149 °F; 5–95% RH (non-condensing |
