20A 208V Input, 24 NEMA 5-20R Outlets, Remote Outlet Switching, Real-Time Power Monitoring, 0U Vertical Mount
[/shortdesc]
[properties]
| Brand |
APC by Schneider Electric |
| Model |
AP8962 |
| Product Type |
NetShelter Switched Rack PDU |
| Form Factor |
0U Vertical |
| Dimensions (H x W x D |
70.5" x 2.2" x 1.7" (1791 x 55 x 44 mm |
| Weight |
15.37 lb (6.97 kg |
| Color |
Black |
| Number of Rack Units |
0U |
| Mounting Mode |
Rack-mounted (Vertical |
| Cooling |
Not specified |
[/properties]
[specifications]
| PDU Type |
Switched (2nd Generation |
| Input Voltage |
208 V (3 Phase |
| Output Voltage |
120 V |
| Input Plug Type |
NEMA L21-20P |
| Input Frequency |
50/60 Hz |
| Line Rated Current |
16 A (Max 20 A |
| Load Capacity |
5760 VA |
| Outlets |
24 × NEMA 5-20R |
| Communication Ports |
Web, SNMP, Telnet |
| Operating Temperature |
23–140 °F (-5–60 °C |
| Storage Temperature |
-13–149 °F (-25–65 °C |
| Operating Humidity |
5–95% |
| Storage Humidity |
5–95% |
| Operating Altitude |
0–10,000 ft |
| Storage Altitude |
0–50,000 ft |
| Compliance |
cUL Listed, UL Listed, FCC Part 15 Class A, ICES-003, UL 60950-1, RoHS, REACh |
| Warranty |
2 years repair or replace |
[/specifications]
[accessories]
| Installation Guide |
Included in the box |
| Rack Mounting Brackets |
Included in the box |
| Serial Configuration Cable |
Included in the box |
| Safety Guide |
Included in the box |
[/accesories]
[specifications]
[/specifications]
Overview
The APC AP8962 Switched Rack PDU delivers efficient, user-configurable power management for demanding IT environments. With outlet-level control, real-time metering, and remote management, it helps prevent downtime, simplifies load balancing, and ensures critical infrastructure operates with stability.
Key Features & Benefits
-
Remote Outlet Control: Switch individual outlets on/off for rebooting devices or restricting access.
-
Power Sequencing: Configure start-up order to avoid inrush current and ensure stable recovery.
-
Real-Time Metering: Monitor connected loads via secure web, SNMP, or Telnet interfaces.
-
Load Shedding: Prioritize key devices and extend uptime during recovery events.
-
Environmental Monitoring: Supports temperature and humidity sensors for proactive alerts.
-
Space-Saving Design: 0U vertical rackmount saves rack space for servers and storage.
Technical Deep Dive
The AP8962 leverages switched PDU technology to provide full control over each connected outlet. This allows administrators to perform power cycling remotely, minimizing the need for onsite interventions and reducing downtime.
Integrated metering and alarms deliver insight into real-time current draw, helping data centers optimize loads and prevent overloads. Outlet sequencing adds another layer of control, preventing circuit trips by staggering equipment startups after outages.
Secure access via web, SNMP, or Telnet enables integration with APC’s centralized management tools like InfraStruxure Central and Capacity Manager. Combined with support for environmental sensors, it provides comprehensive visibility into power and environmental conditions.
Ideal Applications
- Data center racks and network closets
- Enterprise IT deployments with remote management needs
- Critical server and storage systems requiring controlled startup
- Colocation and hosting environments
Frequently Asked Questions (FAQs
Q1: How is the AP8962 installed?
A: It is designed for 0U vertical mounting in standard racks and includes brackets and a configuration cable.
Q2: What performance can I expect?
A: The unit supports up to 20A input with 24 NEMA 5-20R outlets. Load capacity reaches 5760VA. Runtime depends on connected equipment and facility power conditions.
Q3: How is the PDU managed?
A: Management is enabled via secure Web, SNMP, or Telnet interfaces, with compatibility for APC centralized management tools. It also supports temperature and humidity monitoring.
