[shortdesc] 2 MP outdoor AI dome, 3.4-9.8 mm varifocal lens, 40 m IR, Forensic WDR, Lightfinder 2.0, IK10/IP66 housing [/shortdesc]
[properties]
| Model |
AXIS P3275-LVE |
| Product Type |
Outdoor 2 MP AI-powered Network Dome Camera |
| Image Sensor |
1/2.8" progressive scan RGB CMOS |
| Sensor Resolution |
2 MP, up to 1920 x 1080 (16:9 |
| Lens |
Varifocal 3.4-9.8 mm, F1.4-2.7, IR-corrected, remote zoom & focus, P-Iris control |
| Field of View |
Horizontal 100°-32°; Vertical 52°-18° (10 mm variant |
| Minimum Illumination |
Color: 0.08 lux at 50 IRE, F1.4; B/W: 0.02 lux at 50 IRE, F1.4; 0 lux with IR on |
| Day/Night |
Automatic IR-cut filter |
| IR Illumination |
OptimizedIR, 850 nm IR LEDs; range up to 40 m (130 ft or more depending on scene |
| Shutter Speed |
1/37000 s to 2 s |
| Wide Dynamic Range |
Forensic WDR, up to 120 dB (scene dependent |
| Low-light Technology |
Lightfinder 2.0 |
| Built-in Analytics |
AXIS Object Analytics, AXIS Image Health Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection |
| System-on-Chip |
ARTPEC-9 with deep learning processing unit (DLPU |
| Memory |
2 GB RAM; 8 GB Flash |
| Power |
Power over Ethernet (PoE IEEE 802.3af/802.3at Type 1 Class 3 via RJ45 |
| Power Consumption |
Typical 3.4 W (heater off, IR off; max 10 W |
| Operating Conditions |
-40 °C to 50 °C (-40 °F to 122 °F; 10-100% RH, condensing |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F; 5-95% RH, non-condensing |
| Environmental Protection |
IP66, NEMA 4X, IK10 impact-resistant |
| Housing |
Plastic casing with weathershield; polycarbonate hard-coated dome |
| Dimensions (Max Diameter x Max Height |
156 x 183 mm (6.15 x 7.21 in |
| Weight |
840 g (1.9 lb (10 mm variant |
| Edge Storage |
microSD/microSDHC/microSDXC card slot; NAS support |
[/properties]
[specifications]
| Video Compression |
H.264 (Baseline, Main, High, H.265 (Main, AV1, Motion JPEG |
| Max Resolution & Frame Rate |
Up to 1920 x 1080 @ 50/60 fps in all supported resolutions |
| Video Streams |
Up to 20 unique configurable streams; Axis Zipstream in AV1/H.264/H.265; low-latency mode |
| Multi-view Streaming |
Up to 7 individually cropped view areas |
| Signal-to-Noise Ratio |
>55 dB |
| Image Settings |
Saturation, contrast, brightness, sharpness, white balance, exposure control, defog, barrel distortion correction, rotation (0°/90°/180°/270°, mirroring, privacy masks, overlays |
| Network Protocols |
IPv4/IPv6, HTTP/2, HTTPS, TLS, FTP, SFTP, CIFS/SMB, SMTP, SNMP v1/v2c/v3, DNS/DHCP, NTP/PTP/NTS, RTP/RTSP/SRTP, TCP/UDP/IGMP, MQTT, mDNS/Bonjour, LLDP, CDP, QoS, secure syslog, others |
| Standards & Interoperability |
ONVIF Profile G, M, S, T; VAPIX API; compatible with AXIS Camera Station and third-party VMS |
| Cybersecurity Features |
Axis Edge Vault with secure boot, signed OS, secure keystore (FIPS 140-3 level 3 hardware, encrypted filesystem, IEEE 802.1X, HTTPS/HSTS, MACsec, firewall |
| I/O Interfaces |
1 configurable supervised input/output (12 V DC out, max 25 mA via 4-pin terminal block; 1x RJ45 10/100 Mb/s for network & PoE |
| IR Range |
Up to 40 m (130 ft or more depending on scene |
| Operating Angle Adjustment |
Pan +/-190°; tilt -45° to +80°; rotation 95° |
| Compliance & Certifications |
UL/cUL, CE, KC, VCCI, RCM, ICES/FCC Class A, EN 55032/55035, EN 50121-4, EN 61000-6-1/-6-2; IEC/EN 60529 IP66; IEC/EN 62262 IK10; NEMA 250 Type 4X; TAA compliant |
| Operating DORI Distances (10 mm lens |
Detect: 48-135 m; Observe: 19-54 m; Recognize: 9.6-27 m; Identify: 4.8-14 m (wide-tele |
[/specifications]
[accesories]
| Included |
AXIS P3275-LVE Dome Camera; weathershield; terminal block connector; connector guard; cable gasket; owner authentication key; installation guide |
| Optional - Installation Tools |
AXIS T8415 Wireless Installation Tool |
| Optional - Mounting |
AXIS TP3206-E Recessed Mount; AXIS TP3103-E Pendant Kit |
| Optional - Storage |
AXIS Surveillance Cards (microSD/microSDHC/microSDXC |
[/accesories]
AI-Powered Outdoor Dome for Demanding Surveillance
Built on the Axis ARTPEC-9 system-on-chip, the AXIS P3275-LVE 10 mm delivers crisp 2 MP video, powerful edge AI analytics, and reliable performance in harsh outdoor environments. Its varifocal 3.4-9.8 mm lens, Forensic WDR, and Lightfinder 2.0 provide clear detail in challenging light, while OptimizedIR extends visibility up to 40 m at night. With rugged IK10, IP66, and NEMA 4X ratings plus Axis Edge Vault hardware-based security, this dome camera is engineered for professional perimeter and critical site protection globally, backed by comprehensive certifications.
Key Benefits & Features
-
High-quality 2 MP imaging: Delivers 1920x1080 video up to 50/60 fps for detailed scene coverage and accurate event verification.
-
Next-generation AI analytics: ARTPEC-9 with deep learning enables AXIS Object Analytics to detect, classify, and track humans and vehicles directly on the edge.
-
Superior low-light performance: Forensic WDR and Lightfinder 2.0 maintain critical detail in backlit entrances, shaded areas, and low-light perimeters.
-
Rugged outdoor protection: IK10 vandal resistance and IP66/NEMA 4X weather protection keep the camera operational from -40 °C to 50 °C.
-
Built-in cybersecurity: Axis Edge Vault, secure boot, and encrypted storage help safeguard device identity, video integrity, and sensitive credentials.
Ideal Use Cases
- Perimeter protection for warehouses, logistics yards, and distribution centers.
- Surveillance for critical infrastructure, transport hubs, and utilities.
- City surveillance and public safety deployments requiring AI-driven detection.
- Campus and retail exteriors where vandal resistance and low-light detail are essential.
- Privacy-regulated sites leveraging AXIS Live Privacy Shield for dynamic masking in live and recorded video.
Technical Specifications
-
Image sensor: 1/2.8" progressive scan RGB CMOS.
-
Resolution & frame rate: Up to 1920x1080 at 50/60 fps.
-
Lens: 3.4-9.8 mm varifocal, F1.4-2.7 with remote zoom and focus, P-Iris control.
-
Field of view: Horizontal 100°-32°, vertical 52°-18° (10 mm variant.
-
Minimum illumination: Color 0.08 lux, B/W 0.02 lux, 0 lux with IR on.
-
IR illumination: OptimizedIR range up to 40 m or more depending on the scene.
-
Video compression: H.264, H.265, AV1, and Motion JPEG with Axis Zipstream.
-
Operating conditions: -40 °C to 50 °C, 10-100% RH (condensing.
-
Ingress and impact rating: IP66, IK10, NEMA 4X rated outdoor dome.
-
Power: Power over Ethernet IEEE 802.3af/802.3at, max 10 W.
Strengthen Your Outdoor Video Security Today
Deploy the AXIS P3275-LVE 10 mm to gain AI-enhanced awareness, resilient performance, and trusted cybersecurity in a single outdoor-ready dome. Order today.
