Product description Compatible with: LSI 9305-16i; Controller: Broadcom/LSI SAS3216 (16-port SAS3 12Gb/s Firmware (FW: HBA IT Mode (Non-RAID; Data Transfer Rate: 12Gb/s per SAS lane, backward compatible with 6Gb/s/3Gb/s . Host Interface: PCIe 3.0 x8; Internal Connectors: 4x Mini-SAS HD SFF-8643. Direct attach up to 16 drives, and expand via external SAS Expander for large arrays . PERFECT FOR: ZFS, FreeNAS/TrueNAS, unRAID, JBOD, ESXi/Proxmox homelab and data-center storage builds . 4X SFF-8643 to 8482 SAS, 16-Port 12Gbps PCIe 3.0 x8 Packing List: HBA Card ×1; 4x SFF-8643 to 8482 SAS Cables ×4. Cables in box are for SAS drives (SFF-8482. They are not compatible with SATA drives. To connect SATA drives, use SFF-8643 to 4× SATA breakout cables (sold separately or choose our matched HBA + cable kit Built around the Broadcom/LSI SAS3216 controller, this 16-port SAS3 (12Gb/s HBA delivers reliable, IT-mode passthrough for NAS and software-defined storage. The card provides a PCIe 3.0 x8 host interface and four internal Mini-SAS HD (SFF-8643 connectors, enabling direct attachment of up to sixteen SAS/SATA* drives and seamless expansion through external SAS Expanders for large arrays and JBOD deployments. To get you running faster with SAS disks, the package includes 4x SFF-8643 to SFF-8482 SAS cables (with power, ideal for connecting 3.5""/2.5"" SAS hard drives to each SFF-8643 port. Typical use cases include ZFS on TrueNAS, unRAID, Linux mdadm, and virtualization platforms such as VMware ESXi and Proxmox where IT-mode HBAs are preferred for maximum flexibility and performance. LANPAN 2PCS SFF-8643 to 4X SFF-8482 Mini SAS HD Breakout Cable 1.6ft/0.5m, 12... SFF-8087 to 4×SATA Forward Breakout Cable 1.6ft/0.5m – Mini SAS 36-Pin to 4×7... 10GbE SFP+ Network Card Compatible with X520-DA2 PCIe Ethernet Card with 8259... SAS HBA Card Compatible with LSI 9211-8i IT Mode PCIe SATA Expansion Card, 8-... SAS HBA Card Compatible with LSI 9205-8i IT Mode PCIe SATA Expansion Card, 8-... SAS HBA Card Compatible with LSI 9201-8i IT Mode PCIe SATA Expansion Card, 8-... Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 5.0 out of 5 stars 1 — — 4.3 out of 5 stars 8 — 4.7 out of 5 stars 32 Price $32.99$32.99 $14.99$14.99 $47.77$47.77 $45.99$45.99 $45.88$45.88 $71.88$71.88 Product name Breakout Cable Breakout Cable Network Card HBA IT Mode HBA IT Mode HBA IT Mode Controller × × X520-DA2 SAS2008 SAS2308 SAS2008 Data Transfer Rate 12Gbps 6Gbps 10GbE 6Gbps 6Gbps 6Gbps Internal Connectors × × 2× SFP+ 10GbE 2× Mini-SAS SFF-8087 2× Mini-SAS SFF-8087 2× Mini-SAS SFF-8087 Cable 2PCS SFF-8643 to 4×SFF-8482 SAS SFF-8087 to 4×SATA × × 2× SFF-8087 to 4× SATA 2× SFF-8087 to 4× SATA From the brand Previous page SFF-8643 SAS HBA Card Visit the Store SFF-8643 SATA HBA Card Visit the Store SFF-8087 SATA HBA Card Visit the Store SFF-8087 SAS HBA Card Visit the Store SFF-8643 to 4x SFF-8482 SAS HD Visit the Store SFF-8087 to 4×SATA Cable Visit the Store Next page
Features
- Compatible with: LSI 9305-16i; Controller: Broadcom/LSI SAS3216 (16-port SAS3 12Gb/s
- Firmware (FW: HBA IT Mode (Non-RAID; Data Transfer Rate: 12Gb/s per SAS lane, backward compatible with 6Gb/s/3Gb/s
- Host Interface: PCIe 3.0 x8; Internal Connectors: 4x Mini-SAS HD SFF-8643. Direct attach up to 16 drives, and expand via external SAS Expander for large arrays
- PERFECT FOR: ZFS, FreeNAS/TrueNAS, unRAID, JBOD, ESXi/Proxmox homelab and data-center storage builds
- Packing List: HBA Card ×1; 4x SFF-8643 to 8482 SAS Cables ×4. Cables in box are for SAS drives (SFF-8482. They are not compatible with SATA drives. To connect SATA drives, use SFF-8643 to 4× SATA breakout cables (sold separately or choose our matched HBA + cable kit
Specifications
| brand |
LANPAN |
| operating_system |
Linux, Windows, macOS |
| item_weight |
9.6 ounces |
| package_dimensions |
9.8 x 5.9 x 1.57 inches |
| manufacturer |
LANPAN |
| asin |
B0FYX78B6V |
| date_first_available |
November 1, 2025 |
